QSFP+ 40G SR4 300M 850nm Optical Transceiver Module | ||
 | Part Number | QSFP-40G-SR4 |
| Form Factor | QSFP+ | |
| Data Rate | 40G | |
| Protocol | SR4 | |
| Wavelength | 850nm | |
Achieve | 100m | |
| Cable Type | MMF | |
| Connectors | MPO | |
| Transmit power(dBm) | -6~2.4 | |
| Receiving sensitivity(dBm) | -10.3 | |
| Power consumption(W) | <1.5 | |
| Operating case temperature | 0~70℃ | |
| Warranty | 3 years | |
QSFP+ 40G IR4 2KM 1310nm Optical Transceiver Module | ||
 | Part Number | QSFP-40G-IR4 |
| Form Factor | QSFP+ | |
| Data Rate | 40G | |
| Protocol | IR4 | |
| Wavelength | 1310nm | |
Achieve | 2km | |
| Cable Type | SMF | |
| Connectors | 2LC | |
| Transmit power(dBm) | -4~2.3 | |
| Receiving sensitivity(dBm) | -11 | |
| Power consumption(W) | <2.5 | |
| Operating case temperature | 0~70℃ | |
| Warranty | 3 years | |
QSFP+ 40G LR4 10KM 1310nm Optical Transceiver Module | ||
 | Part Number | QSFP-40G-LR4 |
| Form Factor | QSFP+ | |
| Data Rate | 40G | |
| Protocol | LR4 | |
| Wavelength | 1310nm | |
Achieve | 10km | |
| Cable Type | SMF | |
| Connectors | 2LC | |
| Transmit power(dBm) | -7~2.3 | |
| Receiving sensitivity(dBm) | -11.5 | |
| Power consumption(W) | <2.5 | |
| Operating case temperature | 0~70℃ | |
| Warranty | 3 years | |
QSFP+ 40G PSM4 2KM 1310nm Optical Transceiver Module | ||
 | Part Number | QSFP-40G-PSM4-IR |
| Form Factor | QSFP+ | |
| Data Rate | 40G | |
| Protocol | PSM4 | |
| Wavelength | 1310nm | |
Achieve | 2km | |
| Cable Type | SMF | |
| Connectors | MPO | |
| Transmit power(dBm) | -5.5~2.3 | |
| Receiving sensitivity(dBm) | -11.5 | |
| Power consumption(W) | <2.5 | |
| Operating case temperature | 0~70℃ | |
| Warranty | 3 years | |
QSFP+ 40G PSM4 10KM 1310nm Optical Transceiver Module | ||
 | Part Number | QSFP-40G-PSM4-LR |
| Form Factor | QSFP+ | |
| Data Rate | 40G | |
| Protocol | PSM4 | |
| Wavelength | 1310nm | |
Achieve | 10km | |
| Cable Type | SMF | |
| Connectors | MPO | |
| Transmit power(dBm) | -5.5~2.3 | |
| Receiving sensitivity(dBm) | -11.5 | |
| Power consumption(W) | <2.5 | |
| Operating case temperature | 0~70℃ | |
| Warranty | 3 years | |
QSFP+ 40G ER4 40KM 1310nm Optical Transceiver Module | ||
 | Part Number | QSFP-40G-ER4 |
| Form Factor | QSFP+ | |
| Data Rate | 40G | |
| Protocol | ER4 | |
| Wavelength | 1310nm | |
Achieve | 40km | |
| Cable Type | SMF | |
| Connectors | 2LC | |
| Transmit power(dBm) | -2.7~4.5 | |
| Receiving sensitivity(dBm) | -19 | |
| Power consumption(W) | <3.5 | |
| Operating case temperature | 0~70℃ | |
| Warranty | 3 years | |
| QSFP+ 40G SR4 300M 850nm Optical Transceiver Module | |
| Product Features • Multi-rate, up to 10.3125Gb/s per channel • Transmission distance up to 300m OM3 • Hot-swappable QSFP+ package • Single 1x12 MPO socket • Low power consumption • Four-channel full-duplex transceiver module • RoHS-6 compliant and lead-free • +3.3V single power supply • Supports digital diagnostic monitor interface • Case operating temperature commercial: 0°C to +70°C Applications • 40GBASE-SR4 • 40G Ethernet • InfiniBand QDR |
| QSFP+ 40G IR4 2KM 1310nm Optical Transceiver Module | |
| Product Features • Compliant with 40G Ethernet IEEE802.3ba and 40GBASE-IR4 standards • Compliant with QSFP+ MSA standards • Compliant with QDR/DDR InfiniBand data rates • Up to 11.2Gb/s per wavelength data rate • 4 CWDM channel MUX/DEMUX design • Single-mode fiber (SMF) transmission distance up to 2km • Operating temperature: 0~70℃ • Maximum power consumption 2.5W • LC duplex connector • RoHS compliant Applications • 40GBASE-LR4 Ethernet link • InfiniBand QDR and DDR interconnects • Client 40G telecom connections |
| QSFP+ 40G LR4 10KM 1310nm Optical Transceiver Module | |
| Product Features • Compliant with 40G Ethernet IEEE802.3ba and 40GBASE-LR4 standards • Compliant with QSFP+ MSA standards • Compliant with QDR/DDR InfiniBand data rates • Up to 11.2Gb/s per wavelength data rate • 4 CWDM channel MUX/DEMUX design • Up to 10km transmission distance on SMF • Operating temperature: 0~70℃ • Maximum power consumption 2.5W • LC duplex connector • RoHS compliant Applications • 40GBASE-LR4 Ethernet links • InfiniBand QDR and DDR interconnects • Client 40G telecom connections |
| QSFP+ 40G PSM4 2KM 1310nm Optical Transceiver Module | |
| Product Features • Four-channel full-duplex transceiver module • Up to 11.2Gbit/s data rate per channel • Up to 2km single-mode fiber transmission distance • Low power consumption <2.5W, compliant with Class 3 standards • Operating case temperature: 0~70℃ • 3.3V supply voltage • Hot-swappable QSFP form factor • RoHS 6 compliant • Single MPO connector socket • Built-in digital diagnostics Applications • InfiniBand QDR and DDR interconnects • 40G Ethernet • Proprietary high-speed interconnects • Data center |
| QSFP+ 40G PSM4 10KM 1310nm Optical Transceiver Module | |
| Product Features • Four-channel full-duplex transceiver module • Up to 11.2Gbit/s data rate per channel • Up to 10km transmission distance on SMF • Low power consumption <2.5W, compliant with Grade 3 standards • Operating case temperature: 0~70℃ • 3.3V supply voltage • Hot-swappable QSFP form factor • RoHS 6 compliant • Single MPO connector socket • Built-in digital diagnostics Applications • InfiniBand QDR and DDR interconnects • 40G Ethernet • Proprietary high-speed interconnects • Data centers |
| QSFP+ 40G ER4 40KM 1310nm Optical Transceiver Module | |
| Product Features • Compliant with 40G Ethernet IEEE802.3ba and 40GBASE-ER4 standards • Compliant with QSFP+ MSA • Compliant with QDR/DDR InfiniBand data rates • Up to 11.2Gb/s per wavelength data rate • 4 CWDM channel MUX/DEMUX design • Up to 40km transmission distance on SMF • Operating temperature: 0~70℃ • Maximum power consumption 3.5W • LC duplex connector • RoHS compliant Applications • 40GBASE-ER4 Ethernet links • InfiniBand QDR and DDR interconnects • Client 40G telecom connections |
